| WI-FI Specification | Standard | IEEE802.11 b/g/n |
|---|---|---|
| Signal Rate | Up to 300Mbps | |
| Frequency | 2.4G Hz | |
| Wireless Mode | Access Point | |
| Wireless security |
64/128-bit WEP, WPA-PSK/WPA2-PSK(TKIP/AES), SSID Broadcast Enable/disable, Wireless Mac Filtering |
|
| LTE Module Specification (FDD) | Standard | 3GPP E-UTRA LTE Release 11, UE Category 4 |
| Multiplexing | FDD | |
| Supporting BAND | LTE: 900MHz (B8) / 1800MHz (B3)/2100MHz(B1) | |
| RF Paths | 1Tx, 2Rx | |
| Throughput | DL/UL 150Mbps/50Mbps@ 20Mhz | |
| Activation | USIM | |
| Max. Tx Power | 23dBm@ Antenna Port | |
| Hardware Specification | WAN type | LTE Backhaul |
| Interface | 4*RJ-45 ports 10/100/1000M Base-T, USIM, WPS, Factory reset Micro USB, External Power Supply. | |
| LED indicator | PWR, LTE, RJ45x4, WiFi | |
| Antenna | WI-FI: Internal, LTE: External (Main, Diversity) | |
| Power Supply | DC 12V/1A(Output) | |
| Dimension(Lx W x H) | 118(138) x 82 x 26(27) mm | |
| Weight | 230g | |
| Software Specification | WAN type | LTE Backhaul |
| Firmware Update | Local Update , Remote (HTTP-based OTA) | |
| WebUI | For customer configuration | |
| Firewall | MAC / IP / Port Filtering, Port Forwarding, DMZ, URL Filtering | |
| Protocols | TCP / UDP over IPv4 | |
| VPN | Under Certification | |
| Others | DDNS, Super DMZ, Remote Management, KT DMS Interoperability |
