| LTE | HL7528(Sierra) LTE Release9, Category 4 |
|---|---|
| 적용 MODULE LGA(Land Grid Array) type | LTE 850MHz(Band5) 2,100MHz(Band1) Dual Band |
| NAND Flash 2Gbit / LPDDR2 2Gbit | |
| WIFI | IEEE 802.11b/g/n(2.4G) Single SSID, Open/Share/Auto/WPA-PSK/WPA2-PSK |
| CPU | CPU Core MIPS 24KEc 580MHz |
| ROM/RAM | Serial Flash 128Mbit_16Mbyte/1Gbit_128Mbyte F-die DDR2 SDRAM |
| OS | Linux 2.6.36 |
| Ethernet Wireless Switch | 2-Port Ethernet Switch, (RJ45 Ethernet/IP), WAN Port 연동지원, 5V PoE 적용 |
| LTE Antenna | LTE Intenna (2x2 MiMo) MCX Conn, Extemal Wideband Antenna(Option) |
| I/O Connector | UART/RS232(Option), Debug, Smart GPS 연동, GPIO:2(In/Out) Port, 5VDC 입력:1 |
| SIM | USIM (Door Type) |
| 5-LED | Power, CPU States, LAN 1/2, LTE & Weak Signal(Pink), WiFi |
| Power input(Adaptor) | 5VDC/2A(5.5φx2.1φx10mm DC Jack) |
|---|---|
| 차량용 전원장치(Option) | 8~36V 차량용 전원(차량용 퓨즈), ACC OFF/ON 인식 상시전원 전환 지연(2분)회로 적용 |
| Data Transfer Rate | 150Mbps DL / 50Mbps UL(ldle) |
| IP & APN Setting | LTE Network Condition Check & IP Setting |
| NMS 원격관리 | 동작/상태확인/Reset/펌웨어 업그레이드/Log 리스트 확인/그룹관리 등 |
| Internet & M2M Service | FOTA, DDNS, Port Forwarding, DMZ, Firewall, IP/Port Filtening |
| DHCP server, NAT, UPnP server, VPN Passthrough | |
| Secuway/Axgate SSL VPN(Option) | |
| MAC에 고정 IP 할당 기능, 공인 IP | |
| Mechanical | Dimensions:112x78.5x21.7mm, Weight:90g |
| Temperature | Operating:-30℃~70℃, Storage:-40℃~80℃ |
| Humidity | 5%~90% (non-condensing) |
| Standard Packing | LTE Router, Power Adaptor, Ethernet Cable, Manual |
